In ISIS, routers can form neighbor relationships even with different system IDs, provided they are configured to be in the same area and the authentication between them is correctly set up.

SNMP Community String: Enable SNMP community string C1sc0 with read-only permissions.

Interface Index Persistence: Enable interface index persistence.

Restrict SNMP Community: Restrict the SNMP community to only the monitoring server with IP address 198.18.19.100/32.

View-Only Access: Provide view-only access to ospflfEntry and ospfNbrEntry.

Best – 50.50.50.2

2nd Best – 40.40.40.2

3rd Best – 20.20.20.2

44th Best – 30.30.30.2

In an EVPN operation, the PE (Provider Edge) router determines and advertises Ethernet segment reachability by discovering remote ESIs (Ethernet Segment Identifiers) and determining their redundancy mode (all-active or single-active). This is crucial in multihoming scenarios where the PE needs to auto-discover remote PEs and the corresponding redundancy mode. In case of segment failures, PEs withdraw the routes used at this stage to trigger fast convergence by signaling a MAC mass withdrawal on remote PEs3.

The issue of Router 1 failing to establish an OSPF peering with Router 2, and the increase in CPU and memory usage can be attributed to a mismatch in MTU (Maximum Transmission Unit) sizes. In OSPF, for a successful adjacency to be formed, the MTU size on the interfaces that are trying to form this adjacency must match. In this case, changing the MTU to 1524 on Router 1 will make it compatible with Router 2, allowing OSPF peering to be established and customer traffic to pass through successfully.

 In the context of Cisco IOS XR software, the configuration under Option D is appropriate for adding an interface to a bundle using LACP (Link Aggregation Control Protocol). The configuration specifies two Ten Gigabit Ethernet interfaces (TenGigE0/1/0/5 and TenGigE0/1/0/6) with descriptions indicating they are part of “bundle_1_link”. Both interfaces are assigned to “bundle id 1” with a load interval of 30 seconds, ensuring they are part of the same link aggregation group and share traffic load.

 In OSPF, the election of the designated router (DR) and backup designated router (BDR) is based on the OSPF network type. The network types include:

Broadcast: This is the default network type for Ethernet interfaces. In a broadcast network, OSPF elects a DR and BDR. All other routers become DROTHERs. To prevent the election of a DR/BDR, you can configure the interface as non-broadcast (NBMA) using the ip ospf network non-broadcast command.

Point-to-Point: This network type is used for point-to-point links (e.g., serial links). There is no DR/BDR election in point-to-point networks.

Point-to-Multipoint: This network type is used for point-to-multipoint links (e.g., Frame Relay). There is no DR/BDR election in point-to-multipoint networks.

Point-to-Multipoint Non-Broadcast: Similar to point-to-multipoint, but explicitly configured as non-broadcast. There is no DR/BDR election in point-to-multipoint non-broadcast networks.

Loopback: Loopback interfaces are always treated as point-to-point.

Virtual-Link: Used for OSPF virtual links.

Sham-Link: Used for OSPF sham links.

Demand Circuit: Used for demand circuits (e.g., ISDN).

Non-Broadcast: Explicitly configured as non-broadcast. There is no DR/BDR election in non-broadcast networks.

In an MPLS network, the Label Distribution Protocol (LDP) is used to distribute labels which can include segment prefixes. LDP is a protocol that automatically generates and exchanges labels between routers, allowing for the forwarding of packets along a predetermined path without the need for complex lookups in a routing table at every hop.

The issue of the OSPF domain receiving only the 172.17.1.0/24 route and not the default route 0.0.0.0/0 can be resolved by configuring OSPF to propagate default routes. Let’s take a look at the options:

Option A: The configuration includes the following commands:

router ospf 1

default-information originate

end

This configuration generates a default route into the OSPF domain, which is missing in this scenario.

To enable LDP session protection for LDP neighbors within each VRF, the engineer should configure LDP session protection within the individual VRFs. This ensures that LDP sessions are protected at the VRF level, providing security and stability for MPLS-based services. By enabling LDP session protection within each VRF, the router will take appropriate actions to protect LDP sessions against misbehaving neighbors or potential attacks. References: Implementing and Operating Cisco Service Provider Network Core Technologies (SPCOR) v1.0

 BGPsec enhances BGP by adding a layer of security for the AS path attribute. When BGPsec is implemented, updates from eBGP peers include a BGPsec attribute sequence with a public key hash and digital signature. This ensures the authenticity and integrity of the AS path, preventing unauthorized AS numbers from being inserted. References: = Implementing and Operating Cisco Service Provider Network Core Technologies course materials.

The command channel-group 1 mode desirable configures the switch port to actively send PAgP packets to negotiate forming an EtherChannel. PAgP is a Cisco-proprietary protocol used in the automatic creation of EtherChannel links. When set to ‘desirable’, the port actively attempts to form an EtherChannel, which means it sends PAgP packets without waiting for the connected peer to initiate the negotiation.
