ssh ckad00043

You have two deliverables here:

Figure out what RBAC permissions the scraper Deployment needs (the logs will usually show “Forbidden” with the missing verb/resource).

Create a ServiceAccount named scraper in namespace cute-panda (and in practice, you then bind the needed permissions to it and use it in the Deployment so it actually works).

Below is the exact CKAD-style workflow.

1) Find the missing RBAC permissions (use logs + events)

1.1 Identify the pods for the Deployment

kubectl -n cute-panda get deploy scraper

kubectl -n cute-panda get pods -l app=scraper 2>/dev/null || kubectl -n cute-panda get pods

Pick one pod name and check logs:

kubectl -n cute-panda logs deploy/scraper --tail=100

If the pod is crashlooping and logs are short:

POD=$(kubectl -n cute-panda get pods -o jsonpath='{.items[0].metadata.name}')

kubectl -n cute-panda logs "$POD" --previous --tail=200

1.2 Look specifically for “Forbidden” lines

Most apps print errors like:

... is forbidden: User "system:serviceaccount:cute-panda:default" cannot list resource "pods" in API group "" in the namespace "cute-panda"

or cannot get resource "configmaps"...

or cannot watch ...

If you don’t see it in logs, check events:

kubectl -n cute-panda get events --sort-by=.lastTimestamp | tail -n 30

1.3 Extract verb/resource/apiGroup from the error

From a typical Kubernetes RBAC “forbidden” message, capture:

verb: get/list/watch/create/update/patch/delete

resource: pods, configmaps, secrets, deployments, etc.

apiGroup: "" (core), apps, batch, etc.

namespace: cute-panda (this is a namespaced permission if it’s a Role)

You may have multiple “cannot …” lines → you need to allow all of them.

2) Create the ServiceAccount scraper (required by the task)

kubectl -n cute-panda create serviceaccount scraper

kubectl -n cute-panda get sa scraper

3) Create the RBAC objects to grant the needed permissions

The task says “A Deployment needs specific RBAC permissions” — in CKAD, that usually means: Role + RoleBinding (namespaced) bound to your new ServiceAccount.

3.1 Create a Role (template you fill from the log output)

Create scraper-role.yaml:

cat <<'EOF' > scraper-role.yaml

apiVersion: rbac.authorization.k8s.io/v1

kind: Role

metadata:

name: scraper-role

namespace: cute-panda

rules:

# EXAMPLE ONLY: replace these rules with what your logs show

- apiGroups: [""]

resources: ["pods"]

verbs: ["get","list","watch"]

EOF

Apply it:

kubectl apply -f scraper-role.yaml

3.2 Bind the Role to the ServiceAccount

kubectl -n cute-panda create rolebinding scraper-rb \

--role=scraper-role \

--serviceaccount=cute-panda:scraper

Verify:

kubectl -n cute-panda get role scraper-role

kubectl -n cute-panda get rolebinding scraper-rb -o yaml

4) Update the Deployment to use the new ServiceAccount (so it actually works)

Check current SA (likely default):

kubectl -n cute-panda get deploy scraper -o jsonpath='{.spec.template.spec.serviceAccountName}{"\n"}'

Patch it to use scraper:

kubectl -n cute-panda patch deploy scraper -p '{"spec":{"template":{"spec":{"serviceAccountName":"scraper"}}}}'

Rollout:

kubectl -n cute-panda rollout status deploy scraper

Re-check logs to confirm RBAC errors are gone:

kubectl -n cute-panda logs deploy/scraper --tail=100

Do this on ckad00027 and edit the given manifest file (that’s what the task expects).

0) Connect to correct host

ssh ckad00027

1) Open the manifest and identify the container + port

cd /home/candidate/spicy-pikachu

ls -l

sed -n '1,200p' app-deployment.yaml

Confirm the container port is 8081 in the YAML (usually under ports:).

2) Edit the YAML to add a readinessProbe

Edit the file:

vi app-deployment.yaml

Inside the Deployment, locate:

spec:

template:

spec:

containers:

- name: ...

image: ...

Add this under the container (same indentation level as image, ports, etc.):

readinessProbe:

httpGet:

path: /healthz

port: 8081

initialDelaySeconds: 6

periodSeconds: 3

Notes:

Use port: 8081 (because the app runs on 8081).

Ensure indentation is correct (2 spaces per level commonly).

Save and exit.

3) Apply the updated manifest

kubectl apply -f /home/candidate/spicy-pikachu/app-deployment.yaml

4) Ensure the Deployment rolls out successfully

kubectl -n prod rollout status deploy app-deployment

5) Verify the readiness probe is set

Check the probe from the live object:

kubectl -n prod get deploy app-deployment -o jsonpath='{.spec.template.spec.containers[0].readinessProbe}{"\n"}'

And confirm pods are becoming Ready:

kubectl -n prod get pods -l app=app-deployment

If the label selector differs, just:

kubectl -n prod get pods

kubectl -n prod describe pod | sed -n '/Readiness:/,/Conditions:/p'

That completes the task: readiness probe on /healthz, initialDelaySeconds: 6, periodSeconds: 3.

To find the broken pod and store its name and namespace to /opt/KDOB00401/broken.txt, you can use the kubectl get pods command and filter the output by the status of the pod.

kubectl get pods --field-selector=status.phase=Failed -o jsonpath='{.items[*].metadata.namespace}/{.items[*].metadata.name}' > /opt/KDOB00401/broken.txt

This command will list all pods with a status of Failed and output their names and namespaces in the format /. The output is then written to the /opt/KDOB00401/broken.txt file.

To store the associated error events to a file /opt/KDOB00401/error.txt, you can use the kubectl describe command to retrieve detailed information about the pod, and the grep command to filter the output for error events.

kubectl describe pods --namespace | grep -i error -B5 -A5 > /opt/KDOB00401/error.txt

Replace and with the name and namespace of the broken pod you found in the previous step.

This command will output detailed information about the pod, including error events. The grep command filters the output for lines containing "error" and also prints 5 lines before and after the match.

To fix the issue, you need to analyze the error events and find the root cause of the issue.

It could be that the application inside the pod is not running, the container image is not available, the pod has not enough resources, or the liveness probe configuration is incorrect.

Once you have identified the cause, you can take appropriate action, such as restarting the application, updating the container image, increasing the resources, or modifying the liveness probe configuration.

After fixing the issue, you can use the kubectl get pods command to check the status of the pod and ensure

Solution:

To update the nginxsvc service to serve on port 5050, you will need to edit the service's definition yaml file. You can use the kubectl edit command to edit the service in place.

kubectl edit svc nginxsvc

This will open the service definition yaml file in your default editor. Change the targetPort of the service to 5050 and save the file.

To add an HAproxy container named haproxy bound to port 90 to the poller pod, you will need to edit the pod's definition yaml file located at /opt/KDMC00101/poller.yaml.

You can add a new container to the pod's definition yaml file, with the following configuration:

containers:

- name: haproxy

image: haproxy

ports:

- containerPort: 90

volumeMounts:

- name: haproxy-config

mountPath: /usr/local/etc/haproxy/haproxy.cfg

subPath: haproxy.cfg

args: ["haproxy", "-f", "/usr/local/etc/haproxy/haproxy.cfg"]

This will add the HAproxy container to the pod and configure it to listen on port 90. It will also mount the ConfigMap haproxy-config to the container, so that haproxy.cfg is available at /usr/local/etc/haproxy/haproxy.cfg.

To inject the configuration located at /opt/KDMC00101/haproxy.cfg to the container, you will need to create a ConfigMap using the following command:

kubectl create configmap haproxy-config --from-file=/opt/KDMC00101/haproxy.cfg

You will also need to update the args of the poller container so that it connects to localhost instead of nginxsvc. You can do this by editing the pod's definition yaml file and changing the args field to args: ["poller","--host=localhost"].

Once you have made these changes, you can deploy the updated pod to the cluster by running the following command:

kubectl apply -f /opt/KDMC00101/poller.yaml

This will deploy the enhanced pod with the HAproxy container to the cluster. The HAproxy container will listen on port 90 and proxy connections to the nginxsvc service on port 5050. The poller container will connect to localhost instead of nginxsvc, so that the connection is correctly proxied to the new service endpoint.

Please note that, this is a basic example and you may need to tweak the haproxy.cfg file and the args based on your use case.

0) SSH to the correct host

ssh ckad00044

(Optional sanity)

kubectl config current-context

kubectl get ns | grep rapid-goat

1) Inspect the Deployment and current container name

kubectl -n rapid-goat get deploy busybox

kubectl -n rapid-goat get deploy busybox -o jsonpath='{.spec.template.spec.containers[*].name}{"\n"}'

kubectl -n rapid-goat get deploy busybox -o jsonpath='{.spec.template.spec.containers[*].image}{"\n"}'

Note the current container name (likely something like busybox). We need to rename it to musl.

2) Edit the Deployment (best for renaming container)

Renaming a container is easiest with edit:

kubectl -n rapid-goat edit deploy busybox

In the editor, find:

spec:

template:

spec:

containers:

- name:

image:

Change it to:

- name: musl

image: busybox:musl

Save and exit.

3) Ensure the rollout happens and completes

kubectl -n rapid-goat rollout status deploy busybox

4) Verify the new Pod template is correct

Check the Deployment template:

kubectl -n rapid-goat get deploy busybox -o jsonpath='{.spec.template.spec.containers[0].name}{"\n"}{.spec.template.spec.containers[0].image}{"\n"}'

Check running Pods and the image actually used:

kubectl -n rapid-goat get pods -o wide

POD=$(kubectl -n rapid-goat get pods -l app=busybox -o jsonpath='{.items[0].metadata.name}' 2>/dev/null || true)

If you don’t have that label selector, just pick a pod name from kubectl get pods and:

kubectl -n rapid-goat describe pod | sed -n '/Containers:/,/Conditions:/p'

ssh ckad00026

Your job is to edit /home/candidate/credible-mite/web.yaml so it uses APIs supported on Kubernetes 1.29+, then deploy it into namespace garfish.

Because I can’t see your file from here, the most reliable exam approach is:

run a server-side dry-run to reveal the exact deprecated/removed APIs and schema errors

edit the manifest to the modern API versions/fields

re-run dry-run until it passes

apply for real and verify rollout

1) Go to the manifest and run a server-side dry-run

cd /home/candidate/credible-mite

ls -l

sed -n '1,200p' web.yaml

Make sure the namespace exists:

kubectl get ns garfish || kubectl create ns garfish

Now run a server-side dry-run (this catches removed APIs on the cluster):

kubectl apply -n garfish -f web.yaml --dry-run=server

Whatever errors you get here tell you exactly what to fix.

2) Fix the common v1.15 → v1.29 API deprecations

Edit the file:

vi web.yaml

Below are the most common objects from older manifests and how to update them for 1.29+.

A) Deployments / DaemonSets / StatefulSets

Old (v1.15 often used):

extensions/v1beta1 or apps/v1beta1 or apps/v1beta2

New:

apiVersion: apps/v1

Also in apps/v1, .spec.selector is required and must match the pod template labels.

Example conversion:

apiVersion: apps/v1

kind: Deployment

metadata:

name: web

spec:

replicas: 2

selector:

matchLabels:

app: web

template:

metadata:

labels:

app: web

spec:

containers:

- name: web

image: nginx

Key rule:

spec.selector.matchLabels must exactly match spec.template.metadata.labels (at least for the keys you select on).

B) Ingress

Old:

apiVersion: extensions/v1beta1 (or networking.k8s.io/v1beta1)

New:

apiVersion: networking.k8s.io/v1

Required changes:

spec.rules.http.paths[].pathType is required (usually Prefix)

backend format changes from serviceName/servicePort to service.name/service.port.number (or .name for named ports)

Old backend:

backend:

serviceName: web

servicePort: 80

New backend:

backend:

service:

name: web

port:

number: 80

Full path example:

apiVersion: networking.k8s.io/v1

kind: Ingress

metadata:

name: web

spec:

rules:

- host: example.local

http:

paths:

- path: /

pathType: Prefix

backend:

service:

name: web

port:

number: 80

C) CronJob

Old:

apiVersion: batch/v1beta1

New:

apiVersion: batch/v1

Most fields stay the same; just update apiVersion.

D) PodDisruptionBudget

Old:

policy/v1beta1

New:

policy/v1

spec.selector/minAvailable/maxUnavailable remain, but apiVersion changes.

E) RBAC

Usually already:

rbac.authorization.k8s.io/v1 (this is fine)

F) Removed APIs you must delete/replace

If you see these in a v1.15-era manifest, they are removed in modern clusters:

PodSecurityPolicy (policy/v1beta1) is removed. You cannot deploy it on 1.29+. Remove it from the manifest (or replace with whatever your environment uses, but for CKAD tasks you usually delete PSP sections from the file).

Some old admission/alpha resources also removed.

If dry-run complains “no matches for kind … in version …”, that’s your cue.

3) Re-run dry-run until it succeeds

After you edit:

kubectl apply -n garfish -f web.yaml --dry-run=server

Keep iterating until there are no errors.

4) Deploy for real

kubectl apply -n garfish -f /home/candidate/credible-mite/web.yaml

5) Verify everything in namespace garfish

List what was created:

kubectl -n garfish get all

kubectl -n garfish get ingress 2>/dev/null || true

If there is a Deployment, verify rollout:

kubectl -n garfish get deploy

kubectl -n garfish rollout status deploy --all

Check pods/events if something fails:

kubectl -n garfish get pods -o wide

kubectl -n garfish describe pod

kubectl -n garfish get events --sort-by=.lastTimestamp | tail -n 30

Solution:

To allow a pod to send and receive traffic only to and from specific pods, you can use network policies in Kubernetes.

First, you will need to create a network policy that defines the allowed traffic. You can create a network policy yaml file with the following rules:

apiVersion: networking.k8s.io/v1

kind: NetworkPolicy

metadata:

name: newpod-network-policy

namespace: default

spec:

podSelector:

matchLabels:

app: kdsn00201-newpod

ingress:

- from:

- podSelector:

matchLabels:

app: web

- podSelector:

matchLabels:

app: storage

This policy will only allow incoming traffic to the pod with the label app=kdsn00201-newpod from pods with the label app=web or app=storage. If you have different labels on your web and storage pods please update the matchLabels accordingly.

Once you have created the network policy, you can apply it to the cluster by running the following command:

kubectl apply -f .yaml

This will apply the network policy to the cluster, and the newpod will only be able to send and receive traffic to and from the web and storage pods.

Please note that, NetworkPolicy resource is not available by default, you need to enable the NetworkPolicy feature on your Kubernetes cluster. This feature is enabled by default on some clusters and must be explicitly enabled on others. You can check if NetworkPolicy is available by running the command kubectl api-versions | grep networking

Also, you need to ensure that the pods that you want to allow traffic to and from are running on the same namespace.

Solution:

Solution:
