To generate an email alert to admin@contoso.com when CPU percentage utilization for db1 is higher than average, you can use the Azure portal to create an alert rule based on the CPU percentage metric. Here are the steps to do that:

Go to the Azure portal and select your Azure SQL Database server that hosts db1.

Select Alerts in the Monitoring section and click on New alert rule.

In the Condition section, click Add and select the CPU percentage metric.

In the Configure signal logic page, set the threshold type to Dynamic. This will compare the current metric value to the historical average and trigger the alert when it deviates significantly1.

Set the operator to Greater than, the aggregation type to Average, the aggregation granularity to 1 minute, and the frequency of evaluation to 5 minutes.

Click Done to save the condition.

In the Action group section, click Create and enter a name and a short name for the action group.

In the Notifications section, click Add and select Email/SMS message/Push/Voice.

Enter admin@contoso.com in the Email field and click OK.

Click OK to save the action group.

In the Alert rule details section, enter a name and a description for the alert rule, choose a severity level, and make sure the rule is enabled.

Click Create alert rule to create the alert rule.

This alert rule will send an email to admin@contoso.com when the CPU percentage utilization for db1 is higher than average. You can also add other actions to the alert rule, such as calling a webhook or running an automation script

SQL injection attacks are a type of cyberattack that exploit a vulnerability in the application code that interacts with the database. An attacker can inject malicious SQL statements into the user input, such as a form field or a URL parameter, and execute them on the database server, resulting in data theft, corruption, or unauthorized access1.

To protect all the databases on sql37006S95 from SQL injection attacks, you need to follow some best practices for securing your application and database layers. Here are some of the recommended steps:

Use parameterized queries or stored procedures to separate the SQL code from the user input. This will prevent the user input from being interpreted as part of the SQL statement and avoid SQL injection23.

Validate and sanitize the user input before passing it to the database. This will ensure that the input conforms to the expected format and type, and remove any potentially harmful characters or keywords4.

Implement least privilege access for the database users and roles. This will limit the permissions and actions that the application can perform on the database, and reduce the impact of a successful SQL injection attack5.

Enable Advanced Threat Protection for Azure SQL Database. This is a feature that detects and alerts you of anomalous activities and potential threats on your database, such as SQL injection, brute force attacks, or unusual access patterns. You can configure the alert settings and notifications using the Azure portal or PowerShell.

These are some of the steps to protect all the databases on sql37006S95 from SQL injection attacks.

Create an Azure Monitor metric alert rule on database db1 using the metric:

CPU percentage

Configure the condition as:

Aggregation: Average

Operator: Greater than

Threshold: 50

Aggregation granularity / Period: 1 minute

Frequency of evaluation: 1 minute

Evaluation period / Lookback window: 5 minutes

Action group email: admin@contoso.com

Azure SQL Database exposes CPU percentage as a platform metric, and Azure Monitor metric alerts can send notifications through action groups such as email. Microsoft describes SQL Database alerts as metric-based alerts that can send email when metrics such as CPU usage reach a defined threshold.

Azure Portal Method — Recommended for Simulation

Step 1: Open the db1 Azure SQL database

Sign in to the Azure portal.

Search for SQL databases.

Open the database named:

db1

Do not open the SQL logical server unless the alert needs to apply to all databases. This task is specifically for db1, so the alert scope must be the db1 database resource.

Step 2: Create a new alert rule

From the db1 database page:

In the left menu, select Alerts.

Select Create.

Select Alert rule.

Microsoft’s Azure Monitor workflow allows you to create an alert rule directly from the target resource. When you create it from a resource, the resource is automatically set as the alert scope.

Step 3: Confirm the alert scope

On the alert rule page, confirm the scope is the Azure SQL database:

db1

The resource type should be similar to:

SQL database

Microsoft.Sql/servers/databases

If the scope is the SQL server instead of the database, remove it and select the db1 database resource.

Step 4: Add the alert condition

Under Condition, select Add condition.

Choose the metric:

CPU percentage

Sometimes it appears as:

CPU percent

or metric name:

cpu_percent

For Azure SQL Database, CPU percentage represents CPU consumption toward the database workload limit, expressed as a percentage.

Step 5: Configure the signal logic

Configure the alert logic exactly like this:

Setting

Value

Threshold type

Static

Aggregation type

Average

Operator

Greater than

Threshold value

50

Unit

Percent

Aggregation granularity / Period

1 minute

Frequency of evaluation

1 minute

Evaluation period / Lookback window

5 minutes

This means Azure Monitor evaluates the CPU metric every minute, using one-minute metric samples, and fires the alert only when the average CPU percentage is greater than 50% across the five-minute evaluation window.

Be precise here. The task says:

average CPU percentage utilization is greater than 50 percent for five minutes sampled at one-minute intervals

So the correct choices are:

Average

Greater than 50

Every 1 minute

Over the last 5 minutes

Azure Monitor metric alert rules combine the monitored resource, the metric condition, and action groups that run when the condition is met.

Step 6: Create the email action group

Under Actions, select:

Create action group

Configure the basics:

Setting

Value

Subscription

Use the current subscription

Resource group

Use the lab resource group

Action group name

AG-db1-CPU-Email

Display name

db1CPU

Then go to Notifications.

Add a notification:

Setting

Value

Notification type

Email/SMS message/Push/Voice

Name

EmailAdmin

Email

admin@contoso.com

Select OK, then Review + create, then Create.

Action groups define the notification or automation action that runs when an alert fires. Microsoft documents email as a supported action group notification type.

Step 7: Configure alert rule details

Under Details, configure:

Setting

Value

Severity

2 or 3

Alert rule name

db1 CPU greater than 50 percent

Description

Alert when average CPU percentage for db1 is greater than 50 percent for 5 minutes.

Enable upon creation

Yes

Severity is usually not specified by the task, so any reasonable severity is acceptable. In an exam lab, I would use Severity 2 for CPU performance impact.

Step 8: Review and create

Select Review + create.

Confirm the condition says something equivalent to:

Whenever the average CPU percentage is greater than 50

Confirm the evaluation settings are:

Check every 1 minute

Lookback period 5 minutes

Confirm the action group sends email to:

admin@contoso.com

Select Create.

Verification

After creation:

Open db1.

Go to Alerts.

Select Alert rules.

Confirm the alert rule exists and is enabled.

Open the rule and verify:

Scope: db1

Signal: CPU percentage

Aggregation: Average

Operator: Greater than

Threshold: 50

Evaluation frequency: 1 minute

Window size: 5 minutes

Action group: admin@contoso.com

Azure CLI Method

Use this only if the simulation gives you Cloud Shell.

First get the database resource ID:

az sql db show \

--resource-group < resource-group-name > \

--server < sql-server-name > \

--name db1 \

--query id \

--output tsv

Create the action group:

az monitor action-group create \

--resource-group < resource-group-name > \

--name AG-db1-CPU-Email \

--short-name db1CPU \

--action email EmailAdmin admin@contoso.com

Create the metric alert:

az monitor metrics alert create \

--name " db1 CPU greater than 50 percent " \

--resource-group < resource-group-name > \

--scopes < db1-resource-id > \

--condition " avg cpu_percent > 50 " \

--window-size 5m \

--evaluation-frequency 1m \

--action AG-db1-CPU-Email \

--description " Alert when average CPU percentage for db1 is greater than 50 percent for 5 minutes. "

The metric name commonly used for Azure SQL Database CPU percentage in CLI/ARM contexts is:

cpu_percent

SSMS Clarification

SSMS is not the correct tool for this task.

Do not configure Database Mail. Azure SQL Database does not use SQL Server Agent/Database Mail in the same way as SQL Server on a VM or SQL Managed Instance. This requirement is an Azure Monitor metric alert requirement.

Correct tool:

Azure portal > db1 > Alerts > Create alert rule

Wrong tool:

SSMS Database Mail

Final Exam-Lab Configuration

Use this exact configuration:

Resource: db1

Alert type: Metric alert

Metric: CPU percentage

Aggregation: Average

Operator: Greater than

Threshold: 50

Aggregation granularity: 1 minute

Evaluation frequency: 1 minute

Evaluation period/window: 5 minutes

Action group notification: Email

Email recipient: admin@contoso.com

That completes the task.

To enable page compression on the PK_SalesOrderHeader_SalesOrderlD clustered index of the SalesLT.SalesOrderHeader table in db1, you can use the following Transact-SQL script:

-- Connect to the Azure SQL database named db1

USE db1;

GO

-- Enable page compression on the clustered index

ALTER INDEX PK_SalesOrderHeader_SalesOrderlD ON SalesLT.SalesOrderHeader

REBUILD WITH (DATA_COMPRESSION = PAGE);

GO

This script will rebuild the clustered index with page compression, which can reduce the storage space and improve the query performance

The script solution consists of three parts:

The first part is USE db1; GO. This part connects to the Azure SQL database named db1, where the SalesLT.SalesOrderHeader table is located. The GO command separates the batches of Transact-SQL statements and sends them to the server.

The second part is ALTER INDEX PK_SalesOrderHeader_SalesOrderlD ON SalesLT.SalesOrderHeader REBUILD WITH (DATA_COMPRESSION = PAGE); GO. This part enables page compression on the clustered index named PK_SalesOrderHeader_SalesOrderlD, which is defined on the SalesLT.SalesOrderHeader table. The ALTER INDEX statement modifies the properties of an existing index. The REBUILD option rebuilds the index from scratch, which is required to change the compression setting. The DATA_COMPRESSION = PAGE option specifies that page compression is applied to the index, which means that both row and prefix compression are used. Page compression can reduce the storage space and improve the query performance by compressing the data at the page level. The GO command ends the batch of statements.

The third part is optional, but it can be useful to verify the compression status of the index. It is SELECT name, index_id, data_compression_desc FROM sys.indexes WHERE object_id = OBJECT_ID( ' SalesLT.SalesOrderHeader ' );. This part queries the sys.indexes catalog view, which contains information about the indexes in the database. The SELECT statement returns the name, index_id, and data_compression_desc columns for the indexes that belong to the SalesLT.SalesOrderHeader table. The OBJECT_ID function returns the object identification number for the table name. The data_compression_desc column shows the compression type of the index, which should be PAGE for the clustered index after the script is executed.

These are the steps of the script solution for enabling page compression on the clustered index of the SalesLT.SalesOrderHeader table in db1.

To configure high availability for dbl, you can use the failover groups feature of Azure SQL Database. Failover groups allow you to manage the replication and failover of a group of databases across different regions with the same connection strings1. You can choose all, or a subset of, user databases in a logical server to be replicated to another logical server in a different region. You can also specify the failover policy, such as manual or automatic, and the grace period for data loss.

Here are the steps to create a failover group for dbl:

Using the Azure portal:

Go to the Azure portal and select your Azure SQL Database server that hosts dbl.

Select Failover groups in the left menu and click on Add group.

Enter a name for the failover group and select a secondary region that is different from the primary region.

Click on Create a new server and enter the details for the secondary server, such as server name, admin login, password, and subscription.

Click on Select existing database(s) and choose dbl from the list of databases on the primary server.

Click on Configure failover policy and select the failover mode, grace period, and read-write failover endpoint mode according to your preferences.

Click on Create to create the failover group and start the replication of dbl to the secondary server.

Using PowerShell commands:

Install the Azure PowerShell module and log in with your Azure account.

Run the following command to create a new server in the secondary region: New-AzSqlServer -ResourceGroupName < your-resource-group-name > -ServerName < your-secondary-server-name > -Location " < secondary-region-name > " -SqlAdministratorCredentials $(New-Object -TypeName System.Management.Automation.PSCredential -ArgumentList " < your-admin-login > " , $(ConvertTo-SecureString -String " < your-password > " -AsPlainText -Force))

Run the following command to create a new failover group with dbl: New-AzSqlDatabaseFailoverGroup -ResourceGroupName < your-resource-group-name > -ServerName < your-primary-server-name > -PartnerResourceGroupName < your-resource-group-name > -PartnerServerName < your-secondary-server-name > -FailoverGroupName < your-failover-group-name > -Database dbl -FailoverPolicy < manual-or-automatic > -GracePeriodWithDataLossHours < grace-period-in-hours > -ReadWriteFailoverEndpoint " < enabled-or-disabled > "

You can modify the parameters of the command according to your preferences, such as the failover policy, grace period, and read-write failover endpoint mode.

These are the steps to create a failover group for dbl

To configure a disaster recovery solution for db1, you can use the failover groups feature of Azure SQL Database. Failover groups allow you to manage the replication and failover of a group of databases across different regions with the same connection strings1. You can also use active geo-replication as an alternative, but you will need to update the connection strings manually after a failover2.

Here are the steps to create a failover group for db1 with the secondary server in the West US 3 region:

Using the Azure portal:

Go to the Azure portal and select your Azure SQL Database server that hosts db1.

Select Failover groups in the left menu and click on Add group.

Enter a name for the failover group and select West US 3 as the secondary region.

Click on Create a new server and enter the details for the secondary server, such as server name, admin login, password, and subscription.

Click on Select existing database(s) and choose db1 from the list of databases on the primary server.

Click on Configure failover policy and select the failover mode, grace period, and read-write failover endpoint mode according to your preferences.

Click on Create to create the failover group and start the replication of db1 to the secondary server.

Using PowerShell commands:

Install the Azure PowerShell module and log in with your Azure account.

Run the following command to create a new server in the West US 3 region: New-AzSqlServer -ResourceGroupName < your-resource-group-name > -ServerName < your-secondary-server-name > -Location " West US 3 " -SqlAdministratorCredentials $(New-Object -TypeName System.Management.Automation.PSCredential -ArgumentList " < your-admin-login > " , $(ConvertTo-SecureString -String " < your-password > " -AsPlainText -Force))

Run the following command to create a new failover group with db1: New-AzSqlDatabaseFailoverGroup -ResourceGroupName < your-resource-group-name > -ServerName < your-primary-server-name > -PartnerResourceGroupName < your-resource-group-name > -PartnerServerName < your-secondary-server-name > -FailoverGroupName < your-failover-group-name > -Database db1 -FailoverPolicy Manual -GracePeriodWithDataLossHours 1 -ReadWriteFailoverEndpoint " Enabled "

You can modify the parameters of the command according to your preferences, such as the failover policy, grace period, and read-write failover endpoint mode.

These are the steps to create a failover group for db1 with the secondary server in the West US 3 region.

Create an Azure Private Endpoint for the Azure SQL logical server that hosts db1, place the private endpoint in VNET1, and integrate it with the private DNS zone:

privatelink.database.windows.net

This is the correct solution because Azure SQL Database is a PaaS service. You do not assign a private IP directly to db1. Instead, Azure creates a private endpoint network interface in the virtual network. That private endpoint receives a private IP address from a subnet in VNET1, and clients in VNET1 use that private IP path to reach the SQL server. Microsoft defines a private endpoint as a network interface that uses a private IP address from your virtual network to connect privately to a Private Link resource such as Azure SQL Database.

Azure Portal Method — Recommended for Simulation

Step 1: Identify the SQL logical server that hosts db1

Sign in to the Azure portal.

Search for SQL databases.

Open db1.

On the database overview page, identify the Server name.

The private endpoint is created for the Azure SQL logical server, not for the database object alone. For Azure SQL Database, the Private Link resource type is:

Microsoft.Sql/servers

and the target subresource is:

sqlServer

Microsoft lists Azure SQL Database private endpoint DNS configuration under Microsoft.Sql/servers with subresource sqlServer.

Step 2: Open the SQL server networking page

Open the Azure SQL logical server that hosts db1.

In the left menu, go to:

Security > Networking

Select the Private access tab.

Select Create a private endpoint.

Microsoft’s Azure SQL private endpoint workflow is performed from the SQL server resource under Networking > Private access, where you can create or manage private endpoint connections.

Step 3: Configure the private endpoint basics

On the Create private endpoint page:

Setting

Value

Subscription

Use the lab subscription

Resource group

Use the lab resource group

Name

pe-db1-sql

Region

Same region as VNET1, if possible

The name is not exam-critical. The critical part is that the endpoint is associated with VNET1 and the SQL server that hosts db1.

Step 4: Configure the target resource

On the Resource tab, configure:

Setting

Value

Connection method

Connect to an Azure resource in my directory

Resource type

Microsoft.Sql/servers

Resource

SQL logical server that hosts db1

Target sub-resource

sqlServer

Do not choose storage, VM, managed instance, or any unrelated resource type. This is Azure SQL Database, so the target subresource must be sqlServer.

Step 5: Configure VNET1 and subnet

On the Virtual Network tab:

Setting

Value

Virtual network

VNET1

Subnet

Select an available subnet in VNET1

Private IP configuration

Dynamic is fine unless the lab requires static

Azure will create a network interface for the private endpoint and assign it a private IP address from the selected subnet. Microsoft notes that the network interface page for the private endpoint shows the private IP address assigned to the private endpoint connection.

Step 6: Configure private DNS integration

On the DNS tab:

Enable private DNS zone integration.

Use or create the private DNS zone:

privatelink.database.windows.net

Link the private DNS zone to:

VNET1

This is not optional in a clean exam solution. Without DNS integration, clients may still resolve the SQL server name to the public endpoint instead of the private endpoint. Microsoft states that DNS is critical because it resolves the private endpoint IP address, and for Azure SQL Database the recommended private DNS zone is privatelink.database.windows.net.

Step 7: Review and create

Select Review + create.

Confirm:

Resource: SQL logical server hosting db1

Target subresource: sqlServer

Virtual network: VNET1

Private DNS zone: privatelink.database.windows.net

Select Create.

After deployment, the SQL server will have a private endpoint connection associated with VNET1.

Step 8: Approve the private endpoint connection if required

In most same-directory deployments, approval may be automatic. If approval is pending:

Open the SQL logical server.

Go to:

Networking > Private access

Select the pending private endpoint connection.

Select Approve.

Microsoft documents that SQL administrators can approve or reject private endpoint connections from the SQL server private access page.

Step 9: Optional but recommended — Disable public network access

The task only says you need to connect by private IP from VNET1. It does not explicitly say to block public access. But if the exam expects private-only access, then disable public access after the private endpoint works.

On the SQL logical server:

Go to:

Security > Networking > Public access

Set Public network access to:

Disabled

or select:

Deny public network access

Save.

Be careful: Microsoft states that adding a private endpoint does not automatically block public routing to the logical server. Public access must be denied separately if you want private-only access.

How to Connect from SSMS

You should connect from a machine that is inside VNET1, such as an Azure VM joined to VNET1.

Step 1: Test DNS from a VM in VNET1

From a VM in VNET1, run:

nslookup < sql-server-name > .database.windows.net

Expected result: the name should resolve through the private endpoint path and return a private IP address from VNET1’s address space.

Microsoft explains that connection URLs do not change; DNS resolution is overridden so the existing service FQDN resolves to the private endpoint private IP address.

Step 2: Connect with SSMS

In SSMS, connect using the normal Azure SQL server name:

< sql-server-name > .database.windows.net

Then select database:

db1

Use normal SQL authentication or Microsoft Entra authentication.

Do not type the raw private IP address into SSMS unless the lab specifically forces it. For Azure SQL, the correct operational pattern is to connect to the SQL server FQDN and allow private DNS to resolve that FQDN to the private endpoint IP. Direct IP connection can cause TLS/certificate name problems because the server certificate matches the DNS name, not the private IP.

Verification

The task is complete when all of these are true:

Private endpoint exists for the SQL logical server hosting db1.

Target subresource is sqlServer.

The private endpoint is deployed into VNET1.

A private IP address is assigned to the private endpoint NIC.

Private DNS zone privatelink.database.windows.net exists.

The private DNS zone is linked to VNET1.

The SQL server FQDN resolves to the private endpoint private IP from inside VNET1.

SSMS can connect to db1 from a VM or client connected to VNET1.

Final Exam-Lab Action

Use the Azure portal and configure:

SQL server hosting db1

> Networking

> Private access

> Create private endpoint

Resource type: Microsoft.Sql/servers

Target subresource: sqlServer

Virtual network: VNET1

Private DNS zone: privatelink.database.windows.net

Then connect from a VM or client in VNET1 using:

< sql-server-name > .database.windows.net

That is the correct way to ensure db1 is reachable through a private IP address on VNET1.

To prevent db1 from reverting to the last known good query plan, you need to disable the automatic plan correction feature for the database. This feature is enabled by default and allows the Query Store to detect and fix plan performance regressions by forcing the last good plan1. However, if you want to test the performance of different plans without interference from the Query Store, you can turn off this feature by using the ALTER DATABASE SCOPED CONFIGURATION statement2.

Here are the steps to disable the automatic plan correction feature for db1:

Connect to db1 using SQL Server Management Studio, Azure Data Studio, or any other tool that supports Transact-SQL statements.

Open a new query window and run the following command: ALTER DATABASE SCOPED CONFIGURATION SET AUTOMATIC_TUNING (FORCE_LAST_GOOD_PLAN = OFF); GO

This command will disable the automatic plan correction feature for db1 and allow the Query Optimizer to choose the best plan based on the current statistics and parameters3.

To verify that the automatic plan correction feature is disabled for db1, you can query the sys.database_scoped_configurations catalog view. The value of the force_last_good_plan column should be 0 for db1.

These are the steps to disable the automatic plan correction feature for db1.

To enable change data capture (CDC) for db1, you need to run the stored procedure sys.sp_cdc_enable_db in the database context. CDC is a feature that records activity on a database when tables and rows have been modified1. CDC can be used for various scenarios, such as data synchronization, auditing, or ETL processes2.

Here are the steps to enable CDC for db1:

Connect to db1 using SQL Server Management Studio, Azure Data Studio, or any other tool that supports Transact-SQL statements.

Open a new query window and run the following command: EXEC sys.sp_cdc_enable_db; GO

This command will enable CDC for the database and create the cdc schema, cdc user, metadata tables, and other system objects for the database3.

To verify that CDC is enabled for db1, you can query the is_cdc_enabled column in the sys.databases catalog view. The value should be 1 for db1.

These are the steps to enable CDC for db1

To ensure that any enhancements made to the Query Optimizer through patches are available to dbl and db2 on sql37006895, you need to enable the query optimizer hotfixes option for each database. This option allows you to use the latest query optimization improvements that are not enabled by default1. You can enable this option by using the ALTER DATABASE SCOPED CONFIGURATION statement2.

Here are the steps to enable the query optimizer hotfixes option for dbl and db2 on sql37006895:

Connect to sql37006895 using SQL Server Management Studio, Azure Data Studio, or any other tool that supports Transact-SQL statements.

Open a new query window and run the following commands for each database:

-- Switch to the database context

USE dbl;

GO

-- Enable the query optimizer hotfixes option

ALTER DATABASE SCOPED CONFIGURATION SET QUERY_OPTIMIZER_HOTFIXES = ON;

GO

Repeat the same commands for db2, replacing dbl with db2 in the USE statement.

To verify that the query optimizer hotfixes option is enabled for each database, you can query the sys.database_scoped_configurations catalog view. The value of the query_optimizer_hotfixes column should be 1 for both databases.

These are the steps to enable the query optimizer hotfixes option for dbl and db2 on sql37006895.
