350-701 Exam Dumps - Cisco CCNP Security Questions and Answers

RADIUS Change of Authorization (CoA) is a feature of Cisco ASA that allows VPN users to be postured against Cisco ISE without requiring an inline posture node. RADIUS CoA enables the ISE to send a message to the ASA to change the authorization attributes of an existing VPN session, such as the assigned IP address, ACL, or group policy. This way, the ISE can dynamically adjust the access level of the VPN user based on the posture assessment results, without the need for an intermediate device to enforce the policy change12. RADIUS CoA is supported by the ASA since version 9.2.13. References: 1: ASA Version 9.2.1 VPN Posture with ISE Configuration Example - Cisco 2: How To: ISE and ASA Integration using CoA for Posture - Cisco Community 3: How To Configure Posture with AnyConnect Compliance … - Cisco CommunityQUESTION NO: 94

What two mechanisms are used to redirect users to a web portal to authenticate to ISE for guest services?

(Choose two)

A. multiple factor auth

B. local web auth

C. single sign-on

D. central web auth

E. TACACS+

Answer: B, D

 Local web authentication (LWA) and central web authentication (CWA) are two mechanisms that are used to redirect users to a web portal to authenticate to ISE for guest services. Both methods involve the use of a redirect access control list (ACL) that allows the user to access only the web portal URL and blocks all other traffic until the user is authenticated. The difference between LWA and CWA is where the web portal and the authentication logic are hosted.

LWA: The web portal and the authentication logic are hosted on the wireless LAN controller (WLC). The WLC sends a RADIUS access-accept message to the network access device (NAD) along with the redirect ACL and the web portal URL. The NAD then redirects the user to the web portal on the WLC, where the user enters their credentials. The WLC verifies the credentials with the ISE and grants or denies access to the user. The advantage of LWA is that it does not require any configuration on the ISE, but the disadvantage is that it does not support advanced features such as posture assessment, profiling, or authorization policies.

CWA: The web portal and the authentication logic are hosted on the ISE. The WLC sends a RADIUS access-challenge message to the NAD along with the redirect ACL and the web portal URL. The NAD then redirects the user to the web portal on the ISE, where the user enters their credentials. The ISE verifies the credentials and sends a RADIUS access-accept message to the WLC with the authorization profile and the final ACL. The WLC then applies the authorization profile and the final ACL to the user session. The advantage of CWA is that it supports advanced features such as posture assessment, profiling, or authorization policies, but the disadvantage is that it requires more configuration on the ISE.

References :=

Configure Guest Access

Web Authentication Redirection to Original URL

Configure Local Web Authentication with External Authentication

Explanation

Cisco Hybrid Email Security is a unique service offering that combines a cloud-based email security deployment

with an appliance-based email security deployment (on premises) to provide maximum choice and control for

your organization. The cloud-based infrastructure is typically used for inbound email cleansing, while the onpremises appliances provide granular control – protecting sensitive information with data loss

prevention (DLP) and encryption technologies.

The access control rule in the exhibit has the following characteristics:

The rule name is DMZ_Rule and it is enabled.

The action set for this rule is Trust, meaning traffic matching this rule will not be subjected to further inspection.

The source zones are not specified, meaning any zone can match this rule.

The destination zone is DMZ_Inside, meaning only traffic destined to this zone can match this rule.

Therefore, the effect of this rule is that all traffic from any zone to the DMZ_Inside zone will be permitted with no further inspection. This is the correct answer, option A.

The other options are incorrect because they do not match the configuration of the rule or the behavior of the Trust action. Option B is incorrect because traffic will be allowed through to the DMZ_Inside zone, not blocked. Option C is incorrect because traffic will not be inspected before being allowed to the DMZ_Inside zone. Option D is incorrect because traffic does not need to be trusted to be allowed to the DMZ_Inside zone. References:

Firepower Management Center Configuration Guide, Version 6.6 - Access Control Rules

Firepower Management Center Device Configuration Guide, 7.1 - Access Control Policies

How to Deploy FMC/FTD part 2 – Access Control Policies

The switch port MAC address security setting that must be used is sticky. This option allows the switch to dynamically learn the MAC addresses of the devices connected to the port and add them to the running configuration. If the port is shut down or the switch is restarted, the MAC addresses remain associated with the port and are not aged out. This way, the engineer can limit the number of MAC addresses per port and prevent unauthorized devices from accessing the network. The sticky option also allows the engineer to manually configure some MAC addresses and let the switch learn the rest. References:

Configuring Port Security - Cisco (Section: Allowing Traffic Based on the Host MAC Address)

How to configure port-security on Cisco Switch - NetworkLessons.com (Section: Sticky MAC addresses)

Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0 (Module 5.1.1)

Cisco CloudLock is a cloud-native cloud access security broker (CASB) that helps you move to the cloud safely. It protects your cloud users, data, and apps. CloudLock’s simple, open, and automated approach uses APIs to manage the risks in your cloud app ecosystem. With CloudLock you can more easily combat data breaches while meeting compliance regulations1.

Cisco CloudLock provides the following features that meet the requirements of visibility into data transfers as well as protection against data exfiltration:

User security: Cloudlock uses advanced machine learning algorithms to detect anomalies based on multiple factors. It also identifies activities outside allowed countries and spots actions that seem to take place at impossible speeds across distances1.

Data security: Cloudlock’s data loss prevention (DLP) technology continuously monitors cloud environments to detect and secure sensitive information. It provides countless out-of-the-box policies as well as highly tunable custom policies. It also supports inline and out-of-band data inspection and blocking capabilities to protect sensitive data12.

App security: The Cloudlock Apps Firewall discovers and controls cloud apps connected to your corporate environment. You can see a crowd-sourced Community Trust Rating for individual apps, and you can ban or allowlist them based on risk1.

The other solutions do not provide the same level of visibility and protection as Cisco CloudLock:

Cisco Umbrella is a cloud-delivered network security service that provides DNS-layer security, secure web gateway, cloud-delivered firewall, cloud access security broker, and threat intelligence3. It does not offer data security features such as DLP, data inspection, and data blocking4.

Cisco AppDynamics Cloud Monitoring is a cloud-native application performance management solution that helps you monitor, troubleshoot, and optimize your cloud applications. It does not offer user security, data security, or app security features as a CASB solution.

Cisco Stealthwatch is a network traffic analysis solution that provides visibility and threat detection across your network, endpoints, and cloud. It does not offer data security features such as DLP, data inspection, and data blocking.

 3: Cisco Umbrella Packages - Cisco Umbrella 1: Cisco Cloudlock - Cisco 2: Cisco Cloudlock Cisco Cloudlock: Secure Cloud Data 4: Easy to Deploy & Simple to Manage CASB Solution - Cisco Umbrella : Cisco AppDynamics Cloud Monitoring : Cisco Stealthwatch - Cisco

Explanation

Vendors, security researchers, and vulnerability coordination centers typically assign vulnerabilities an identifier that’s disclosed to the public. This identifier is known as the Common Vulnerabilities and Exposures (CVE).

CVE is an industry-wide standard. CVE is sponsored by US-CERT, the office of Cybersecurity and

Communications at the U.S. Department of Homeland Security.

The goal of CVE is to make it’s easier to share data across tools, vulnerability repositories, and security

services.

 The strongest security possible for SNMPv3 requires both authentication and encryption, which is achieved by using the priv security level. Authentication ensures that the message is from a valid source, and encryption scrambles the content of the packet to prevent it from being learned by an unauthorized source. The auth sha and priv aes 256 parameters specify the algorithms used for authentication and encryption, respectively. SHA is more secure than MD5, and AES 256 is more secure than DES or 3DES. Therefore, option D is the correct answer, as it uses the priv security level, the SHA algorithm for authentication, and the AES 256 algorithm for encryption. The other options either use a lower security level (noauth or authNoPriv), a weaker encryption algorithm (des or 3des), or no encryption at all. References :=

SNMP Configuration Guide, Cisco IOS XE Release 3SE (Catalyst 3850 Switches) - SNMP Version 3

Configuration Template for SNMPv3 - Cisco Community

SNMP Version 3 - Cisco

 Cisco ISE is a solution that allows an administrator to provision, monitor, and secure mobile devices on Windows and Mac computers from a centralized dashboard. Cisco ISE integrates with Mobile Device Management (MDM) servers to provide necessary insight into the posture of mobile devices and enforce network access policies. Cisco ISE can also perform device registration, remediation, and periodic compliance checks on mobile devices. Cisco ISE can also issue remote actions on the device through the MDM server, such as full wipe, corporate wipe, and PIN lock. Cisco ISE can also augment endpoint data with information from the MDM server that cannot be gathered using the Cisco ISE profiling services. References:

Integrate XenMobile Mobile Device Management (MDM) with Cisco Identity Services Engine (ISE)

Cisco Identity Services Engine Administrator Guide, Release 2.4 - Mobile Device Manager Interoperability with Cisco ISE

Cisco ISE Integration with Mobile Device Management (MDM)

sfr {fail-open | fail-close [monitor-only]} <- There's a couple different options here. The first one is fail-open which means that if the Firepower software module is unavailable, the ASA will continue to forward traffic. fail-close means that if the Firepower module fails, the traffic will stop flowing. While this doesn't seem ideal, there might be a use case for it when securing highly regulated environments. The monitor-only switch can be used with both and basically puts the Firepower services into IDS-mode only. This might be useful for initial testing or setup.

The login block-for command sets a limit on the maximum number of failed login attempts allowed within a defined period of time. If this limit is exceeded, no further logins are allowed for the specified period of time. This feature is designed to protect the router from denial-of-service and dictionary attacks. The syntax of the command is as follows:

login block-for attempts within

The  parameter specifies the duration of the quiet period in seconds. The  parameter specifies the number of failed attempts that trigger the quiet period. The  parameter specifies the time window in seconds for counting the failed attempts.

In this question, the command login block-for 100 attempts 4 within 60 means that if four failures occur in 60 seconds, the router goes to quiet mode for 100 seconds. During the quiet period, no login attempts are accepted, and the router responds with the message “Login disabled for seconds due to too many failed login attempts.” After the quiet period expires, the router resumes normal login operations.

The other options are incorrect because they do not match the command syntax or the expected behavior of the login block-for feature.

References :=

Some possible references for this question are:

User Security Configuration Guide - Cisco IOS Login Enhancements-Login Block

Configuring Login Block

Restrict login attempts : login block-for command

When applied to a router, which command would help mitigate brute-force password attacks against the router?
