The correct answer is C and D. A heavy forwarder and an indexer are the Splunk components that can break a stream of syslog inputs into individual events.

A universal forwarder is a lightweight agent that can forward data to a Splunk deployment, but it does not perform any parsing or indexing on the data. A search head is a Splunk component that handles search requests and distributes them to indexers, but it does not process incoming data.

A heavy forwarder is a Splunk component that can perform parsing, filtering, routing, and aggregation on the data before forwarding it to indexers or other destinations. A heavy forwarder can break a stream of syslog inputs into individual events based on the line breaker and should linemerge settings in the inputs.conf file1.

An indexer is a Splunk component that stores and indexes data, making it searchable. An indexer can also break a stream of syslog inputs into individual events based on the props.conf file settings, such as TIME_FORMAT, MAX_TIMESTAMP_LOOKAHEAD, and line_breaker2.

A Splunk component is a software process that performs a specific function in a Splunk deployment, such as data collection, data processing, data storage, data search, or data visualization.

Syslog is a standard protocol for logging messages from network devices, such as routers, switches, firewalls, or servers. Syslog messages are typically sent over UDP or TCP to a central syslog server or a Splunk instance.

Breaking a stream of syslog inputs into individual events means separating the data into discrete records that can be indexed and searched by Splunk. Each event should have a timestamp, a host, a source, and a sourcetype, which are the default fields that Splunk assigns to the data.

The correct answer is B. The network input in Splunk might be found in the $SPLUNK_HOME/etc/apps/$appName/local/inputs.conf file.

A network input is a type of input that monitors data from TCP or UDP ports. To configure a network input, you need to specify the port number, the connection host, the source, and the sourcetype in the inputs.conf file. You can also set other optional settings, such as index, queue, and host_regex1.

The inputs.conf file is a configuration file that contains the settings for different types of inputs, such as files, directories, scripts, network ports, and Windows event logs. The inputs.conf file can be located in various directories, depending on the scope and priority of the settings. The most common locations are:

$SPLUNK_HOME/etc/system/default: This directory contains the default settings for all inputs. You should not modify or copy the files in this directory2.

$SPLUNK_HOME/etc/system/local: This directory contains the custom settings for all inputs that apply to the entire Splunk instance. The settings in this directory override the default settings2.

$SPLUNK_HOME/etc/apps/$appName/default: This directory contains the default settings for all inputs that are specific to an app. You should not modify or copy the files in this directory2.

$SPLUNK_HOME/etc/apps/$appName/local: This directory contains the custom settings for all inputs that are specific to an app. The settings in this directory override the default and system settings2.

Therefore, the best practice is to create or edit the inputs.conf file in the $SPLUNK_HOME/etc/apps/$appName/local directory, where $appName is the name of the app that you want to configure the network input for. This way, you can avoid modifying the default files and ensure that your settings are applied to the specific app.

The other options are incorrect because:

A. There is no network directory under the apps directory. The network input settings should be in the inputs.conf file, not in a separate directory.

C. There is no udp.conf file in Splunk. The network input settings should be in the inputs.conf file, not in a separate file. The system directory is not the recommended location for custom settings, as it affects the entire Splunk instance.

D. The var/lib/splunk directory is where Splunk stores the indexed data, not the input settings. The homePath setting is used to specify the location of the index data, not the input data. The inputName is not a valid variable for inputs.conf.

https://docs.splunk.com/Documentation/Splunk/latest/Admin/Outputsconf

# Compression

#

# This example sends compressed events to the remote indexer.

# NOTE: Compression can be enabled TCP or SSL outputs only.

# The receiver input port should also have compression enabled.

[tcpout]

server = splunkServer.example.com:4433

compressed = true

https://docs.splunk.com/Documentation/Splunk/8.2.2/Data/Howdoyouwanttoadddata

The fastest way to add data to your Splunk Cloud instance or Splunk Enterprise deployment is to use Splunk Web. After you access the Add Data page, choose one of three options for getting data into your Splunk platform deployment with Splunk Web: (1) Upload, (2) Monitor, (3) Forward The Upload option lets you upload a file or archive of files for indexing. When you choose Upload option, Splunk Web opens the upload process page. Monitor. For Splunk Enterprise installations, the Monitor option lets you monitor one or more files, directories, network streams, scripts, Event Logs (on Windows hosts only), performance metrics, or any other type of machine data that the Splunk Enterprise instance has access to.

The correct answer is C. /var/log/host_460352847/bar/file/foo.txt.

The monitor stanza in inputs.conf is used to configure Splunk to monitor files and directories for new data. The monitor stanza has the following syntax1:

[monitor://]

The input path can be a file or a directory, and it can include wildcards (*) and regular expressions. The wildcards match any number of characters, including none, while the regular expressions match patterns of characters. The input path is case-sensitive and must be enclosed in double quotes if it contains spaces1.

In this case, the input path is /var/log//bar/.txt, which means Splunk will monitor any file with the .txt extension that is located in a subdirectory named bar under the /var/log directory. The subdirectory bar can be at any level under the /var/log directory, and the * wildcard will match any characters before or after the bar and .txt parts1.

Therefore, the file /var/log/host_460352847/bar/file/foo.txt will be matched by the monitor stanza, as it meets the criteria. The other files will not be matched, because:

A. /var/log/host_460352847/temp/bar/file/csv/foo.txt has a .csv extension, not a .txt extension.

B. /var/log/host_460352847/bar/foo.txt is not located in a subdirectory under the bar directory, but directly in the bar directory.

D. /var/log/host_460352847/temp/bar/file/foo.txt is located in a subdirectory named file under the bar directory, not directly in the bar directory.

Setting: ignoreOlderThan = Description: "Causes the input to stop checking files for updates if the file modification time has passed the threshold." Default: 0 (disabled)

https://docs.splunk.com/Documentation/Splunk/8.0.4/Data/Whitelistorblacklistspecificincomingdata

"It is not necessary to define both an allow list and a deny list in a configuration stanza. The settings are independent. If you do define both filters and a file matches them both, Splunk Enterprise does not index that file, as the blacklist filter overrides the whitelist filter." Source:https://docs.splunk.com/Documentation/Splunk/8.1.0/Data/Whitelistorblacklistspecificincomingdata

The serverclass.conf file controls how deployment apps and configurations are distributed from the Deployment Server to its Deployment Clients. Within this configuration, attribute values can be defined at multiple levels, and Splunk applies them based on a defined order of precedence — from general to most specific.

The correct order of evaluation (lowest to highest precedence) is:

[global] — applies to all server classes and clients unless overridden.

[serverClass:<name>] — applies to all clients in that specific server class.

[serverClass:<name>:app:<appname>] — applies only to a specific app within that server class and overrides previous settings.

This means that values set in the [serverClass::app:] stanza take priority over those in [serverClass:], which in turn override values in [global].

Example (from serverclass.conf):

[global]

whitelist.0 = *

[serverClass:web_servers]

whitelist.0 = web01*

blacklist.0 = test*

[serverClass:web_servers:app:web_monitoring]

restartSplunkWeb = true

Here, restartSplunkWeb = true in the app stanza overrides any inherited setting from the global or class level.

Reference (Splunk Documentation):

Splunk® Enterprise Admin Manual → Deploy configurations using deployment server

serverclass.conf.spec and example → “Precedence of attributes: global < serverClass: < serverClass::app:”

Splunk Docs: “How the deployment server works”
