CKA Exam Dumps - Linux Foundation Kubernetes Administrator Questions and Answers

solution

F:\Work\Data Entry Work\Data Entry\20200827\CKA\6 B.JPG

F:\Work\Data Entry Work\Data Entry\20200827\CKA\6 C.JPG

F:\Work\Data Entry Work\Data Entry\20200827\CKA\6 D.JPG

Kubect1 get po -o wide

Using JsonPath

kubect1 get pods -o=jsonpath='{range

items[*]}{.metadata.name}{"\t"}{.status.podIP}{"\n"}{end}'

kubect1 get po nginx-dev -o

jsonpath='{.spec.containers[].image}{"\n"}'

kubect1 get pods--sort-by=.metadata.creationTimestamp

Task Summary

SSH into cka000060

Add the Argo CD Helm repo named argo

Generate a manifest (~/argo-helm.yaml) for Argo CD version 7.7.3

Target namespace: argocd

Do not install CRDs

Just generate, don’t install

✅ Step-by-Step Solution

1️⃣ SSH into the correct host

ssh cka000060

⚠️ Required — skipping this = zero score

2️⃣ Add the Argo CD Helm repository

helm repo add argo https://argoproj.github.io/argo-helm

helm repo update

✅ This adds the official Argo Helm chart source.

3️⃣ Generate Argo CD Helm chart template (version 7.7.3)

Use the helm template command to generate a manifest and write it to ~/argo-helm.yaml.

helm template argocd argo/argo-cd \

--version 7.7.3 \

--namespace argocd \

--set crds.install=false \

> ~/argo-helm.yaml

argocd → Release name (can be anything; here it's same as the namespace)

--set crds.install=false → Disables CRD installation

> ~/argo-helm.yaml → Save to required file

✅ 4️⃣ Verify the generated file (optional but smart)

head ~/argo-helm.yaml

Check that it contains valid Kubernetes YAML and does not include CRDs.

???? Final Command Summary

ssh cka000060

helm repo add argo https://argoproj.github.io/argo-helm

helm repo update

helm template argocd argo/argo-cd \

--version 7.7.3 \

--namespace argocd \

--set crds.install=false \

> ~/argo-helm.yaml

head ~/argo-helm.yaml # Optional verification

kubectl get po nginx -o

jsonpath='{.spec.containers[].image}{"\n"}'

SOLUTION:

[student@node-1] > ssh ek8s

kubectl cordon k8s-master

kubectl drain k8s-master --delete-local-data --ignore-daemonsets --force

apt-get install kubeadm=1.20.1-00 kubelet=1.20.1-00 kubectl=1.20.1-00 --disableexcludes=kubernetes

kubeadm upgrade apply 1.20.1 --etcd-upgrade=false

systemctl daemon-reload

systemctl restart kubelet

kubectl uncordon k8s-master

A screen shot of a computer AI-generated content may be incorrect.

Task Summary

Create an Ingress named echo in the sound-repeater namespace that:

Routes requests to /echo on host example.org

Forwards traffic to service echoserver-service

Uses service port 8080

Verification should return HTTP 200 using curl

✅ Step-by-Step Answer

1️⃣ SSH into the correct node

As shown in the image:

bash

CopyEdit

ssh cka000024

⚠️ Skipping this will result in a ZERO score!

2️⃣ Verify the namespace and service

Ensure the sound-repeater namespace and echoserver-service exist:

kubectl get svc -n sound-repeater

Look for:

echoserver-service ClusterIP ... 8080/TCP

3️⃣ Create the Ingress manifest

Create a YAML file: echo-ingress.yaml

apiVersion: networking.k8s.io/v1

kind: Ingress

metadata:

name: echo

namespace: sound-repeater

annotations:

nginx.ingress.kubernetes.io/rewrite-target: /$1

spec:

rules:

- host: example.org

http:

paths:

- path: /echo

pathType: Prefix

backend:

service:

name: echoserver-service

port:

number: 8080

4️⃣ Apply the Ingress resource

kubectl apply -f echo-ingress.yaml

5️⃣ Test with curl as instructed

Use the exact verification command:

curl -o /dev/null -s -w "%{http_code}\n" http://example.org/echo

✅ You should see:

200

✅ Final Answer Summary

ssh cka000024

kubectl get svc -n sound-repeater

# Create the Ingress YAML

cat < echo-ingress.yaml

apiVersion: networking.k8s.io/v1

kind: Ingress

metadata:

name: echo

namespace: sound-repeater

annotations:

nginx.ingress.kubernetes.io/rewrite-target: /$1

spec:

rules:

- host: example.org

http:

paths:

- path: /echo

pathType: Prefix

backend:

service:

name: echoserver-service

port:

number: 8080

EOF

kubectl apply -f echo-ingress.yaml

curl -o /dev/null -s -w "%{http_code}\n" http://example.org/echo

Task Summary

You are managing a WordPress Deployment in namespace relative-fawn.

Deployment has 3 replicas.

Pods are not starting due to high resource requests.

Your job:✅ Adjust CPU and memory requests so that all 3 pods evenly split the node’s capacity.

Step-by-Step Solution

1️⃣ SSH into the correct host

bash

CopyEdit

ssh cka000058

???? Skipping this will result in a zero score.

2️⃣ Check node resource capacity

You need to know the node’s CPU and memory resources.

bash

CopyEdit

kubectl describe node | grep -A5 "Capacity"

Example output:

yaml

CopyEdit

Capacity:

cpu: 3

memory: 3Gi

Let’s assume the node has:

3 CPUs

3Gi memory

So for 3 pods, divide evenly:

CPU request per pod: 1

Memory request per pod: 1Gi

⚠️ In the actual exam, check real values and divide accordingly. If the node has 4 CPUs and 8Gi, you'd allocate ~1.33 CPUs and ~2.66Gi RAM per pod (rounded reasonably).

3️⃣ Edit the Deployment

Edit the WordPress deployment in the relative-fawn namespace:

kubectl edit deployment wordpress -n relative-fawn

Look for the resources section under spec.template.spec.containers like this:

resources:

requests:

cpu: "1"

memory: "1Gi"

If the section doesn’t exist, add it manually.

Save and exit the editor (:wq if using vi).

4️⃣ Confirm changes

Wait a few seconds, then check:

kubectl get pods -n relative-fawn

Ensure all 3 pods are in Running state.

You can also describe a pod to confirm resource requests are set:

kubectl describe pod -n relative-fawn | grep -A5 "Containers"

ssh cka000058

kubectl describe node | grep -A5 "Capacity"

kubectl edit deployment wordpress -n relative-fawn

# Set CPU: 1, Memory: 1Gi (or according to node capacity)

kubectl get pods -n relative-fawn
