220-1201 Exam Dumps - CompTIA A+ Questions and Answers

When a laptop powers on but the screen is blank, the quickest way to isolate the problem is to connect to an external monitor. This helps determine if the issue is with the laptop display or with the graphics subsystem.

From CompTIA A+ 220-1101 Official Study Guide, Objective 4.1 – Troubleshoot common hardware problems:

“A blank screen on a laptop with power indicators lit should be tested with an external display first to rule out a faulty screen or ribbon cable.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 4: Laptop Display Troubleshooting

CompTIA Exam Objectives 220-1101, Domain 4.1

============

A hard disk drive (HDD), especially if it's older or nearly full, is the most common cause of slow startup times in laptops. HDDs are much slower than SSDs and can significantly bottleneck the boot process.

From CompTIA A+ 220-1101 Official Study Guide, Objective 4.1 – Troubleshoot common hardware problems:

“A slow startup or sluggish system performance is commonly due to a failing or fragmented hard disk drive (HDD). Replacing with an SSD can greatly improve boot times and overall system responsiveness.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 4: Troubleshooting PC Hardware

CompTIA Exam Objectives 220-1101, Domain 4.1

============

If a laptop shuts down when undocked and remains powered off even with a new charging cable, the internal battery is likely faulty and cannot hold a charge. Replacing the battery is the next troubleshooting step.

From the CompTIA A+ 220-1101 Official Study Guide, Objective 4.1 – Troubleshoot common hardware problems:

"If a laptop only works when docked or connected to AC power, and a replacement cable does not resolve the issue, the internal battery may need to be replaced."

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 4: Troubleshooting Mobile Devices

CompTIA Exam Objectives 220-1101, Domain 4.1

============

Channel configuration(e.g.,dual-channel,quad-channel) determines how memory modules communicate with the memory controller. Usingmatched pairs in dual- or quad-channel setupscan significantlyincrease memory bandwidth, improving performance — especially for gaming and video-intensive tasks.

Option A (Error correction):ECC RAM is used in servers for reliability, not performance or gaming.

Option B (RAM voltage):Affects compatibility and overclocking but not bandwidth.

Option D (Physical size):Refers to module form factor (e.g., DIMM, SO-DIMM) and does not impact bandwidth.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 3.2: Given a scenario, install RAM types.

SAS (Serial Attached SCSI) is a high-performance drive interface commonly found in enterprise environments and servers due to its reliability and speed. While SATA is more common in consumer systems, SAS is specifically designed for mission-critical applications, offering features like full-duplex operation and compatibility with SATA drives.

A valid public IP address must fall outside the private IP address ranges:

10.0.0.0 to 10.255.255.255

172.16.0.0 to 172.31.255.255

192.168.0.0 to 192.168.255.255

66.157.195.20 is outside these ranges, making it a public IP address.

Why Not A, C, D: These IPs fall within private IP address ranges.

CompTIA A+ Exam Reference: Core 1 (220-1201), Section 2.6, IP addressing​.

Comprehensive and Detailed Step-by-Step Explanation:

Wi-Fi Analyzer:

A Wi-Fi analyzer is a tool used to detect and analyze wireless networks, even those that are not broadcasting their SSIDs (hidden networks).

It provides detailed information about nearby networks, including signal strength, channel usage, and security protocols.

In this case, the Wi-Fi analyzer can identify the hidden networks that users are connected to, which are not visible on the standard user interface.

Incorrect Options:

A. Cable tester: A cable tester is used to test the integrity of physical network cables. It does not detect wireless networks or SSIDs.

B. Toner probe: A toner probe is used to trace and identify cables within a wiring system. It is not applicable to wireless network analysis.

D. Loopback plug: A loopback plug is used to test the functionality of a network port or NIC. It is unrelated to identifying hidden wireless networks.

Key Takeaway:

The most effective tool for identifying hidden wireless networks is a Wi-Fi analyzer, as it can detect networks that are not broadcasting their SSIDs.

Paper jams and smudging in high-volume printers are often caused bydirty or worn rollers. Rollers are responsible for feeding the paper through the printer. Over time, they accumulate dust, toner residue, or wear out, resulting in misfeeds or jams. Cleaning or replacing them typically resolves this issue.

Option A (Factory reset):A full reset does not directly address mechanical issues like dirty rollers or smudging. It’s a last resort and more relevant to configuration or software-related issues.

Option C (Change toner cartridges):While toner quality can affect print quality, it won’t usually cause jams or widespread smudging unless the cartridge is leaking — which is less likely across multiple users.

Option D (Replace the fuser):A damaged fuser could cause smudging, but this is typically after extensive use and is not the first thing to check. Fuser issues also usually present more persistent, uniform smudges.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 3.7: Given a scenario, troubleshoot common printer problems.

A common reason for aPOST failureafter a motherboard installation isimproperly seated RAM. The system requires working memory to successfully complete POST. Reseating (removing and reinserting) the RAM ensures it's making proper contact with the motherboard.

Option A:Flashing the BIOS is not possible if the system won’t POST.

Option B:A dead CMOS battery can cause BIOS settings to reset, but it usually won’t prevent POST entirely.

Option D:Reinstalling the old motherboard is premature — basic troubleshooting steps should be completed first.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 3.5: Given a scenario, troubleshoot problems related to motherboards, RAM, CPU, and power.

A managed switch provides advanced features such as traffic monitoring and VLAN configuration, allowing a technician to view network statistics for devices on the local subnet.

Why Not B (Router): A router connects different networks and directs traffic between them but does not provide detailed subnet-level statistics.

Why Not C (Access point): Access points provide wireless connectivity but lack traffic monitoring features.

Why Not D (Firewall): A firewall filters traffic but is not used for monitoring detailed statistics on a local subnet.

CompTIA A+ Exam Reference: Core 1 (220-1201), Section 2.6, network monitoring tools​.
